CONSTEEL CONSTEELCONSTEEL's monolithics are indispensable materials used in steelmaking refractory lining installation and maintenance process, which remarkably enhance the longivity of refractory linings and apparently cut down the operation cost of steelmalkers.
The CMR series ramming mass has excellent anti-erosion, anti-corrosion , thermal shock resistance and other characteristics while formulated depending on the following features of your particular smelting conditions.
The specific steel category, grades and alloy composition analysis of customers' target products;
The specific smelting furnaces dimensions and the application positons;
The specific smelting shift features at site.etc.
Consteel CMG series magnesia-based patching mix is specially used for cold and hot repairing of slagline layer and other local wearing positions of EAF furnace,RH furnace and ladles. This series is made of selected magnesia and regenerated magnesia based on optimal grain size distribution formulation by introducing preferred compound binder, compound sintering agent and a certain proportion of plasticizer as addictive. Thus the bonding strength and adhesion rate of the patching mix are considerably improved. Besides, according to the various wearing mechanism of patched position of furnace, the formula can be appropriately adjusted by adding a certain amount of anti-slag agent to improve the slag resistance.
The Consteel CMC series ladle permanent lining castables are designed according to specific features of various ladles and positions by processing with superior grain size distribution of selected high quality bauxite, spinel, and corundum material with various composite addictives as foamer activator and water-reducing agent,etc which enable the castable features in various properties range from high refractoriness, vast BD scope, high strength, supreme thermal insulation performance, high temperature volume stability to anti-abrasion. Thus this series is pretty able to meet specific application requirement of our steel-making customers.
Consteel's CMPR series plastic repairing refractory is one monolithic with quick dry out capabilities that can withstand service temperatures of 1 600X3 .This moldable refractory is formulated by super-duty high alumina chemically bonded raw-material with excellent adhesion which is primarily designed for rapid repairs to brick and monolithic linings that can be installed using pneumatic hammer or hand rammed widely used at the roof place of EAF and some repairing position of ladles. Our products features as following
High refractoriness
Thermal shock resistance
High mechanical strength
Sound resistance to wear, erosion
Sound plasticity performance
Long shelf life and easily fabrication
Long service life
Consteel's CMFS filler sand is formulated by most compatible composition including addictive with favorable grain size distribution which thus features as following and widely utilized in EAF's EBT and ladles nozzle applications.
Low thermal conductivity property at various temperature scope which help form appropriate sintered layer to support high self-pouring ratio higher than 98%;
Low sintering temperature which enable quick sintering formation;
No contamination to molten steel due to inert reaction to steel and extremely low solubility;
High refractoriness under load which ensure the stable sintered layer in various conditions;
High fluidity characteristic which guarantee the successful drainage during the pcuring step.
